AFI MRV 2-speed Wiper Motor

MRV 80° Sweep 2 Speed Wiper Motor With 2 1/2 Shaft Product

• Easily power 22 deluxe arm / blade combination, or a 20 arm / blade combination at sweeps of 80 degrees or less
• Factory pre-set sweep of 80° adjustable to 45°, 60°, 80°
• Corrosion-resistant casing
• Heavy-duty motor with right angle drive
• Two-speed motor, can be operated as one speed
• Solid brass knurled drive nut with brass and stainless steel drive shaft
• Adjustable right or left self parking, coast to park
• Includes 5 amp fuse and holder
• Stainless steel fasteners and mounting bracket
• Use with three-position switch (not included)
• Compact Size: 7.625 x 4 x 2
• Stall torque: 109in-lbs (125 kgf/cm: 12.3Nm)
• Stall Current: 11.5 - 13.0 amps
• No load current: 0.5 - 1.2 amps

MRV 80° Sweep 2 Speed Wiper Motor With 3 1/2 Shaft Product

• Easily power 22 deluxe arm / blade combination, or a 20 arm / blade combination at sweeps of 80 degrees or less
• Factory pre-set sweep of 80 degrees adjustable to 45 degrees, 60degrees, 80 degrees
• Corrosion-resistant casing
• Heavy-duty motor with right angle drive
• Two-speed motor, can be operated as one speed
• Solid brass knurled drive nut with brass and stainless steel drive shaft
• Adjustable right or left self parking, coast to park
• Includes 5 amp fuse and holder
• Stainless steel fasteners and mounting bracket
• Use with three-position switch (not included)

MRV 110° Sweep 2 Speed Wiper Motor With 2 1/2 Shaft Product

• Easily power 22" deluxe arm / blade combination, or a 20" arm / blade combination at sweeps of 80 degrees or less
• Factory pre-set sweep of 110deg adjustable to 45deg, 60deg, 80deg, or 110deg
• .625" diameter shaft (16mm)
• Corrosion-resistant casing
• Heavy-duty motor with right angle drive
• Two-speed motor, can be operated as one speed
• Solid brass knurled drive nut with brass and stainless steel drive shaft
• Adjustable right or left self parking, coast to park
• Includes 5 amp fuse and holder
• Stainless steel fasteners and mounting bracket
• Use with three-position switch (not included)
• Compact Size: 7.625; x 4 x 2
• Stall torque: 109in-lbs (125 kgf/cm: 12.3Nm)
• Stall Current: 11.5 - 13.0 amps
• No load current: 0.5 - 1.2 amps

MRV 110° Sweep 2 Speed Wiper Motor With 3 1/2 Shaft Product

• Easily power 22" deluxe arm / blade combination, or a 20" arm / blade combination at sweeps of 80 degrees or less
• Factory pre-set sweep of 110deg adjustable to 45deg, 60deg, 80deg, or 110deg
• .625" diameter shaft (16mm)
• Corrosion-resistant casing
• Heavy-duty motor with right angle drive
• Two-speed motor, can be operated as one speed
• Solid brass knurled drive nut with brass and stainless steel drive shaft
• Adjustable right or left self parking, coast to park
• Includes 5 amp fuse and holder
• Stainless steel fasteners and mounting bracket
• Use with three-position switch (not included)
• Compact Size: 7.625 x 4 x 2
• Stall torque: 109in-lbs (125 kgf/cm: 12.3Nm)
• Stall Current: 11.5 - 13.0 amps
• No load current: 0.5 - 1.2 amps
